K-Cup Rotary Coffee Capsule Filling Sealing Machine
- PRODUCT DETAIL
Kcup Rotary Coffee Capsule Filling Sealing Machine with Tempered Glass is specially designed for kcups compatible coffee capsules packing. Romiter coffee capsule filling and sealing machines applied with famous electrical and pneumatic components.
Table of Contents
Feature of Rotary Kcups Capsules Filling Sealing Machine
- The complete process flow is fully automatic.
- PLC control can keep the machine work stable. touch screen control with English and Chinese languages.
- Machine frame use U-steel with Waterproof and rust prevention process, Out packed by Stainless steel #304.
- All components are from famous brand company, all of them are produced under strict standards, so their quality are amazing good
- moving molds are made by Alumite material , extraordinary durable and sanitary.All the parts of machine contact with powder are made of stainless steel SUS304.
- No capsule, no fill (if capsule is missed in position then this position will not be filled and sealed)
Spcification of RMY Rotary Kcups Filling Sealing Machine
| Model | RMY-1 | RMY-2 | RMY-3 |
| Filling heads | 1 | 2 | 3 |
| Filling Head Type | Horizontal or Vertical | ||
| Capacity(pcs/hour) | 1200 | 2400 | 3600 |
| Filling volume | 3-30g | ||
| Accurate | ≦±0.2g | ||
| Power | 2.5kw | 3kw | 3.5kw |
| Power source | AC 380v/50 Hz 3 phases | ||
| Air consumption | 0.7m3/min | ||
| Heating temperature | 0-400℃ | ||
| Weight | 600 kg | 650kg | 700kg |
| Dimension(mm) | 1660*1090*1700 | 1700*1190*1700 | 1800*1290*1700 |
Note: We can provide customized coffee capsule filling and sealing machine according to customer’s requirement.
