Plastic Coffee Cup Filling Sealing Machine

Plastic Coffee Cup Filling Sealing Machine is a multi-functional high-speed full automatic machine specially designed for liquid or semi-liquid(such as coffee powder, tea powder, cocoa powder etc water, milk, yogurt, olive oil, fruit juice, tomato sauce, honey) to be filled and sealed. The machine applied with world famous electrical and pneumatic components. High quality, high stability, long se ...
  • PRODUCT DETAIL

Plastic-Coffee-Cup-Filling-Sealing-Machine-with-Glass-Cover

Plastic Coffee Cup Filling Sealing Machine is a multi-functional high-speed full automatic machine specially designed for liquid or semi-liquid(such as coffee powder, tea powder, cocoa powder etc water, milk, yogurt, olive oil, fruit juice, tomato sauce, honey) to be filled and sealed. The machine applied with world famous electrical and pneumatic components. High quality, high stability, long service life. All the parts of machine are made of food grade #304 stainless steel.

Linear-type-K-Cup-Coffee-Capsule-filling-sealing-machine-3

  1. Plastic Coffee Cup Filling Sealing Machine is a multi-functional high-speed full automatic machine for different size of cups acoording to clients’ requirements, such as K-cup, nespresso cups, lavazza blue cups and so on.
  2. Romiter Plastic Coffee Cup Filling Sealing Machine applied with world famous electrical and pneumatic components. All the parts of machine contact with powder are made of stainless steel.
    Photoelectric sensor track ensure accurate sealing;
  3. Twice sealing, sealing pressure can be adjusted according to customer requirements as easy or difficult to tear, reflecting greater humanization design;
  4. Configuration: this machine uses the channel steel, welded together, after 3 times anti-rust treatment, outsourcing #304 stainless steel. Exposed parts are made of rust-proof handle.
  5. Romiter coffee powder and coffee capsule filling sealing machine adopt famous brands touch screen and PLC (Germany Simens), temperture controller and encoder (Japan Omron), motor (Japan Mitsubishi), switch (France Schneider), cylinder and solenoid valve (Taiwan AirTAC). These brands we install on our machine are stable, and it is easy to buy and replace in your domestic market. Our machines suit for Europe standard, with 3 pcs emergency stop buttons, one is on the control plate, two one the both size of the machine.

Linear-type-K-Cup-Coffee-Capsule-filling-sealing-machine-2

Structure of Plastic Coffee Cup Filling Sealing Machine

  1. Aluminum mould: Aluminum Acid-resistant mould, with no deformation, corrosion-resistant features, high hardness, long service life;
  2. Rack section: Made of high quality carbon steel welded together, spray paint, then covered with 304 stainless steel, touching the ground with strong bolts. Can also make the whole machine stainless steel;
  3. Transmission system: Well-known brands of motor, reducer, transmission, cam-splitters, template chains, such as: Mitsubishi Electric;
  4. Falling cups system: Machine automatically one by one fall cup, stable and efficient;
  5. Filling system: Storage tanks made of #304 stainless steel, volume can be customized. Filling volume can be adjusted freely, accurate high precision, anti-leak, you can add mixing system insulation and heating systems;
  6. Put on foils: Automatic suck foils by vacuum then put above the cups, high accuracy, saving time and efficiency;
  7. Sealing system: Constant temperature (intelligent temperature) twice sealing, sealing heads made of copper, good thermal conductivity, strong;
  8. Cutting film: Cold cutting, cut out the covering film easy opening;
  9. Put out cups: Can be equipped with a vacuum suction cup arm system, external conveyor;
  10. Control system: Using Omron and Siemens PLC programmable , relays, the main components
    fordomestic and international famous brands,Siemens touch screen.

RML series automatic filling and sealing machine, adopting chain step transmission mechanism. 24 hours of continuous work.  The electrical and pneumatic components are Germany, and France, and Japan and other international brands. Can be configured as required joint control system human-machine interface, PLC .

Working Process of  Plastic Coffee Cup Filling Sealing Machine

  1. Automatic falling cups one by one;
  2. Automatic falling filters;
  3. Manually adjust the filter’s position
  4. Automatic screw filling coffee powder with high precision(volume can be adjusted by yourself on machine);
  5. Automatic press coffee powder tight;
  6. Automatic mixing tank;
  7. Automatic sucking and putting foils;
  8. Automatic first sealing;
  9. Automatic second sealing,make suer completely sealed;
  10. Automatic push out th finished coffee capsule.

Advantage of Plastic Coffee Cup Filling Sealing Machine

  1. According to client’s special requirements, provides the special design, more than 10 years experience in cup filling and sealing machines, professional designer and worker so serve you.
  2. Each machine with a strict inspection before out of storage, each machine is made of SUS304 and use world famous electrical and pneumatic components;
  3. Within Warranty period, if under the usage of instruction sheet, any product broken or damage, we will offer the repair service.

Parameter Table of Coffee Cup Filling Sealing Machine

ModelRML-4RML-8RML-12RML-16
Head Number481216
Capacity2400320048006400
ApplicationStandard size of Nespresso, Kcup, Lvazza, etc. filling volume can be adjusted!
Sealing materialplastic roll film and pre-cut aluminum lids(Recommend)
Voltage380V/50Hz/3phases (also can be customized!)
Power4.5kw/h5.5kw/h6.5kw/h7.5kw/h
Air Pressure0.6-0.95MPa
Air Consump.(m3/min)0.650.70.850.95
Dimension(mm)3000*650*17003100*650*17003200*750*17003200*880*1700
Weight (kg)600Kg650Kg750Kg950Kg

Working Video of Coffee Cup Filling Sealing Machine

Following is New Design Vertical Powder Screw Feeding Type



Company Profile

Romiter Group is a market leading designer and a manufacturer of coffee capsule filling sealing machinery, include coffee capsule packing machine, coffee capsules filling sealing machine, nespresso capsules filling sealing machine, k-cup filling sealing machine, lavazza blue capsules filling sealing machine, coffee pod filling sealing machine, coffee pod packing machine, coffee bean roasting machinecoffee capsules carton box packing machine, manual coffee capsules sealing machine
