Full Automatic Caffitaly Capsules Packing Machine with Empty Cup Forming Function

Caffitaly Coffee Capsules Filling Sealing Machine with Capsule Forming Function is our advanced technology for coffee capsule filling sealing. This machine combine empty coffee capsules forming machine and coffee capsules filling sealing machine, which makes this caffitaly coffee capsules machine can complete empty coffee cup making, filling, sealing in one machine. Table of Contents Paramet ...
  • PRODUCT DETAIL

Caffitaly Coffee Capsule System

Caffitaly Coffee Capsules Filling Sealing Machine with Capsule Forming Function is our advanced technology for coffee capsule filling sealing. This machine combine empty coffee capsules forming machine and coffee capsules filling sealing machine, which makes this caffitaly coffee capsules machine can complete empty coffee cup making, filling, sealing in one machine.

Caffitaly-Coffee-Capsules-Filling-Sealing-Machine-with-Empty-Capsule-Forming-Function

Empty-Coffee-Capsules-Forming-Machineautomatic-linear-type-coffee-capsule-filling-sealing-machine-6

Parameter Table of Caffitaly Coffee Capsules Filling Sealing Machine


No.NameTechnical parameters
1Punch frequency7-15time/min1—5pcs/time
2Capacity3500-3600 pcs/h(according 5pcs/time,12time/min)
3Max. Forming size250×110(mm2)(Maximum)
4Adjustable stokeNoramal 20—125mm, maximum 200mm
5Coffee capsule typeAccording clients’ request
6MaterialPP 0.45—0.9×250mm Composite alu film 0.05-0.12×250mm Diameter of the scroll hole 70—76mm
7Heating powerforming:3KW sealing:1.5KW
8Total power10 Kw
9Pump capacity>0.2m3(provide by yourself) Pressure:0.5—0.8Mpa
10CoolingTap water or recycle water 60L/h
11Dimension4200×660×1600mm(L×W×H)
12Weight1650kg



Working Process of Caffitaly Capsules Filling Sealing Machine


1). Automatic Forming Empty Caffitaly Capsules

PP-material-for-caffitaly-coffee-capsules-forming

PP material for Caffitaly Coffee Capsules Forming

Caffitaly-Coffee-Capsules-Forming-Mould

Caffitaly Coffee Capsule Forming MouldCaffitaly-Coffee-Capsules-Forming

2). Auto feed inner filter layer before fill powder

Caffitaly-Coffee-Capsule-Bottom-Filter-Install

3). Auto Filling Coffee Powder and press powder

Caffitaly-Coffee-Powder-Filling

4). Caffitaly Capsule Top Filter Install

Caffitaly-Capsule-Top-Filter-Install

5). Automatic Roll Film Aluminium Lid Sealing (photoelectric tracking type)

Automatic-Roll-Film-Aluminium-Lid-Sealing

6). Automatic output final caffitaly coffee capsule

Automatic-output-final-caffitaly-coffee-capsule

Working Video of Caffitaly Coffee Capsules Filling Sealing Machine


Final Caffitaly Coffee Capsules


Caffitaly-Coffee-Capsules Caffitaly-Coffee-Capsules-2

RM series coffee capsule/cup filling and sealing machine is used for coffee capsules/cups filling with coffee powders or other kinds of powder products like tea powder , cocoa powder etc. It is our patent machine specially designed for fill small coffee capsule cups.

we have successful experience design and manufacture for all kinds of coffee capsules : very small cups, the special filling part for the fluffy coffee powder, and press function to ensure all fluffy powder into the cup/capsule container. also some complicated methods as for the plastic filter layer before fill the powder and even filter paper layer after fill powder , to cover the powder top.

We have over 2 years experience in this machine and exported over 50 machines to USA, Israel , Middle East , South America etc.
